GreenGirt Delta
Adjustable System

GreenGirt Delta™ Adjustable System allow for flexibility to meet building demands with the best practice thermally broken cladding support system. Every project has its own unique set of issues that sub-framing systems must be able to adapt to meet today’s building challenges. The current demands of today’s energy codes and design requirements create constructibility dilemmas that have to be overcome.

We make the complex simple

GreenGirt Delta™ Adjustable System offers a continuous insulation solution for exterior wall and plane deviations using structural composite metal hybrid (CMH) components that provide industry-leading thermal efficiency design and eliminate thermal bridging from metal framing and through-wall fasteners.

GreenGirt Delta™ Adjustable System provides a CMH solution for structural misalignment from a small fraction of an inch to larger out of plumb issues for vertical and horizontal installation. The system is available with 18 segmented options and a variety of adjustability from .25“ – 4.5“ to meet unique project needs.
product-greengirt-adjustable

For Architects

Innovative, Highest Sustainable Thermal Efficiencies, Engineered, Proven, Ease of Use, Cost Effective.

We understand the need for versatile materials in architectural design. Our products and attachment systems are designed for frequent changes in continuous insulation and facade design, while providing solutions to meet the demands for energy efficiencies and budget constraints. Easy to specify and designed as a universal cladding attachment system, GreenGirt Delta™ Adjustable Systems can be installed on any substrate, for retrofit or new construction and for any building height.

For Installers

Quality, Cost, Delivery, Service, Schedule.

Our background in facade installation and decades of real-world experience drive an understanding of cladding systems and the building envelope. Most importantly, we know that time is money! Knowledge of field applications for cladding attachments has allowed fully engineered GreenGirt Delta™ Adjustable Systems to be designed for maximized ease of use in field installation, utilizing minimal parts and pieces and manufacturing applications to meet schedule demands. Our technical support program is available to provide services from engineering to field installation training and project assistance.

GreenGirt Delta™ Adjustable Continuous Insulation System
Dual Grip, an all-in-one retention system for rails and insulation.
  • Structurally engineered for vertical and horizontal applications
  • Thermally modeled to achieve efficiencies of 92-98%
  • No through-insulation fasteners or blind fastening
  • Eliminates thermal bridging
  • Tested and approved ASTM E84 Class A rating, compliant with NFPA 285
  • Universal cladding attachment design
  • Easily install and adjust with a single piece design
  • Range of cavity depths accommodated
  • Dual Grip insulation and rail retention system
  • Cost-effective solution

GreenGirt Delta™ Adjustable System – Horizontal or Vertical

GreenGirt Delta Z-Profile Adjustability Chart
https://i0.wp.com/greengirt.com/wp-content/uploads/2020/08/GreenGirt_Adjustable_0004.jpg?fit=785%2C728&ssl=1
GreenGirt Delta™ CMH Base Bracket with Dual Grip™ Retention Technology – A One-Piece Design

Simple. Ease of Use. Cost Effective. Universal Cladding Attachments

Our Adjustable Bracket with Dual Grip™ retention technology is a simple one-piece design that can be used for vertical or horizontal cladding applications. GreenGirt Delta™ Adjustable Systems are the best practice universal fastening solution to meet the unique challenges sub-framing systems demand. This industry-leading composite metal hybrid (CMH) thermally broken cladding support system allows you to adapt and meet today’s building challenges of facade attachment configurations. GreenGirt Delta™ Adjustable Systems comes with Dual Grip™ retention technology for clip, rail, and insulation retention.

https://i0.wp.com/greengirt.com/wp-content/uploads/2020/08/GreenGirt_Adjustable_0005.jpg?fit=785%2C728&ssl=1
CMH HZ Clip – (Horizontal Applications)

The CMH HZ Clip allows GreenGirt Delta™ Adjustable Systems to convert to a horizontal system and provides maximum thermal efficiency.

The GreenGirt Delta™ CMH Horizontal (HZ) Clip is used to attach horizontal hat channels, which allows for direct cladding attachment. If building wall studs are uneven or spaced in an inconsistent manner, or cladding is of irregular sizes, the GreenGirt Delta Adjustable System provides an effective method for cladding attachment.

https://i0.wp.com/greengirt.com/wp-content/uploads/2020/08/GreenGirt_Adjustable_0006.jpg?fit=785%2C728&ssl=1
Metal HZ Clip – Galvanized Steel or Aluminum (Horizontal Applications)

The Metal HZ Clip allows the GreenGirt Delta™ Adjustable System to convert to a horizontal system while providing optimal thermal break options.

The Metal HZ Clip uses the same installation principles as the CMH HZ Clip. The only change is in the ability to use a metal clip instead of the CMH HZ Clip. The Metal HZ Clip is used with the GreenGirt CMH Base Bracket for horizontal applications.

https://i0.wp.com/greengirt.com/wp-content/uploads/2020/08/GreenGirt_Adjustable_0007.jpg?fit=785%2C728&ssl=1
CMH L Rail – (Vertical Applications)

The GreenGirt Delta™ CMH Base Bracket is the main support system for vertical cladding applications and provides maximum thermal efficiency.

The vertical CMH L Rail is used for a direct cladding attachment. This provides an effective method for cladding attachment for uneven building walls, inconsistent wall spacing, or irregular sized cladding. The vertical CMH L Rail also allows hat channels to be horizontally installed for use in certain wall assembly applications. The CMH L Rail is used with the GreenGirt Adjustable Base Bracket for vertical applications.

https://i0.wp.com/greengirt.com/wp-content/uploads/2020/08/GreenGirt_Adjustable_0008.jpg?fit=785%2C728&ssl=1
Metal L Rail – Galvanized Steel or Aluminum (Vertical Applications)

The GreenGirt Delta™ CMH Base Bracket is the main support system for vertical cladding applications while providing optimal thermal break options.

The vertical metal L Rail utilizes the same installation principles as the vertical CMH L Rail. The only change is in the ability to use a metal L Rail material instead of CMH. The metal L Rail is used with the GreenGirt Delta Adjustable Base Bracket for vertical applications.

GreenGirt Delta™ Adjustable System – Components

https://i0.wp.com/greengirt.com/wp-content/uploads/2020/08/GreenGirt_Adjustable_0011.jpg?fit=640%2C594&ssl=1
GreenGirt Delta™ CMH Bracket – Adjustability Range
GreenGirt Delta Bracket Depth2″3″4″5″6″
Adjustability Range2.25″ – 6.5″3.25″ – 7.5″4.25″ – 8.5″5.25″ – 9.5″6.25″ – 10.5″
https://i0.wp.com/greengirt.com/wp-content/uploads/2020/08/GreenGirt_Adjustable_0012.jpg?fit=785%2C728&ssl=1
CMH Clip – Horizontal
Product NumberLength (in)Standard Depths (in)
CMH HZC6″2″, 3″, 4″, 5″, 6″
https://i0.wp.com/greengirt.com/wp-content/uploads/2020/08/GreenGirt_Adjustable_0010.jpg?fit=785%2C728&ssl=1
Metal Clip – Horizontal
Product NumberLength (in)Standard Depths (in)
MGAL HZC6″2″, 3″, 4″, 5″, 6″
MALU HZC6″2″, 3″, 4″, 5″, 6″
https://i0.wp.com/greengirt.com/wp-content/uploads/2020/08/GreenGirt_Adjustable_0014.jpg?fit=785%2C728&ssl=1
CMH L Rail – Vertical
Product NumberLength (ft)Standard Depths (in)
CMH VR88′2″, 3″, 4″, 5″, 6″
GREENGirt Adjustable
Metal L Rail – Vertical
Product NumberMetal TypeLength (ft)Standard Depths (in)
MGAL VR10Galvanized10′2″, 3″, 4″, 5″, 6″
MALU VR10Aluminum10′2″, 3″, 4″, 5″, 6″

GreenGirt Delta™ Adjustable System – Sustainability

SMARTci Systems and GreenGirt z-girt sub-framing products are designed with sustainability at the forefront. From the beginning, our daily routines have integrated a belief in healthy construction throughout the company’s manufacturing and product development teams. We truly understand that through improved material production processes, recycling, materials substitution, innovative construction methods, building for disassembly and deconstruction, use of cutting edge and eco-friendly materials, we are helping to lower the environmental impact on the planet.

Superior in Thermal Efficiency for Best Practice Exterior Wall Solutions with NO Through-Wall Fasteners or Thermal Bridging from Metal Components.

GreenGirt Adjustable System Thermal Insulation section
Thermal illustration using GreenGirt Adjustable System

18.6 Effective R-Value + 96% Efficiency | 4“ Mineral Wool Insulation

3“ GreenGirt CMH L rail system fastened to 4“ GreenGirt Delta™ CMH bracket spaced 32“ O.C. vertically & 16“ O.C. horizontally attached to concrete substrate with 4“ mineral wool insulation
